Ficha técnica
¿Necesita información técnica sobre este sistema de perfiles? Haga clic para descargar una hoja de especificaciones dedicada.- Dimensiones
- 36mm x 78mm (h x w)
- Grosor de la base
- 1.5mm
- Techniques:
- Techo
- Interio/Exterior
- Interior
- Acabado
- Fine structured scratch resistant powder coating: black, white
- Clasificación del IP
- IP20
- Prueba del hilo incandescente
- 960°C
- CRI
- 90+
- Garantía
- 5 años en lámparas LED, 2 años en drivers
- Módulo de iluminación lineal
-
High power LED line
2700K, 3000K, 4000K
Non-dimmable, Dali/Pushdim: Flicker-free (AM dimming) - Módulo de iluminación spot
-
LED Down:
LED Array:
Medium (25°), Flood (40°)
2700K, 3000K, 4000K
Non-dimmable, Trailing edge, 1-10V/Pushdim, Dali
Rektor LED:
LED Array
h 360° v -90°/+90° adjustable
Medium (25°), Flood (40°)
2700K, 3000K, 4000K
Non-dimmable, Trailing edge, 1-10V/Pushdim, Dali
![Base Profile MP78](https://mdlr-prd-pltn-ods-web-assets.azureedge.net/modular/asset/84100/LINED-MP78-BASE-01.jpg?rendition=productdetail&v=Ni8xNi8yMDIyIDE6Mzk6MTggUE02MzMx)
Base Profile MP78
This base profile is merely 2mm thick and made of aluminium to ensure minimum weight, strength and durability. It comes with a maximum extruded length of 4 meters, thus offering the double benefit of preventing bending during transportation and making the profile easy to handle during installation.
![Cover MP78](https://mdlr-prd-pltn-ods-web-assets.azureedge.net/modular/asset/84099/LINED-MP78-COVER-01.jpg?rendition=productdetail&v=Ni8xNi8yMDIyIDE6Mzk6MTggUE02Mjgx)
Cover MP78
This aluminium cover matches the material of the base profile to ensure a consistent look. Click in-and-out, even after installation, to remove it without having to dismount the profile.
![Diffuser MP78](https://mdlr-prd-pltn-ods-web-assets.azureedge.net/modular/asset/84098/LINED-MP78-POLY-01.jpg?rendition=productdetail&v=Ni8xNi8yMDIyIDE6Mzk6MTggUE01NjM5)
Diffuser MP78
Made of polycarbonate, this is a durable diffuser which keeps its quality over time. Click it-in and out for an easy installation and dismounting.
Módulo de iluminación spot
Módulo de iluminación spot
![LED Down](https://mdlr-prd-pltn-ods-web-assets.azureedge.net/modular/asset/106444/IMGDTL-PROF-MP78-LED-900-MODULE-WHSTR-BLSTR-01-2954-x-2953.jpg?rendition=productdetail&v=OS8yMy8yMDIyIDk6Mzg6NTMgQU01MzEzMzEx)
LED Down
Especificaciones básicas
- 2700K, 3000K, 4000K
- No regulable, Trailing edge, 1-10V/Pushdim, Dali
- 1056lm (2700K), 1106lm (3000K), 1194lm (4000K)
![](/globalassets/icons/Casambi-transparant.png?v=49d7d8)
![](/globalassets/icons/hue-transparant.png?v=4a6e2c)
![Rektor LED](https://mdlr-prd-pltn-ods-web-assets.azureedge.net/modular/asset/106445/IMGDTL-PROF-MP78-REKTOR-WHSTR-WHSTR-05-2954-x-2953.jpg?rendition=productdetail&v=OS8yMy8yMDIyIDk6NDI6NDQgQU00NTQwMzMx)
Rektor LED
Especificaciones básicas
- 2700K, 3000K, 4000K
- No regulable, Trailing edge, 1-10V/Pushdim, Dali
- 916lm (2700K), 900lm (3000K), 1049lm (4000K)
![](/globalassets/icons/Casambi-transparant.png?v=49d7d8)
![](/globalassets/icons/hue-transparant.png?v=4a6e2c)
Módulo de iluminación lineal
Módulo de iluminación lineal
Linear LED Fortimo LEDline
Especificaciones básicas
- 2700K, 3000K, 4000K
- No regulable, Dali/Pushdim
- >2000lm/m
