Resumen técnico
Resumen técnico
Ficha técnica
¿Necesita información técnica sobre este sistema de perfiles? Haga clic para descargar una hoja de especificaciones dedicada.- Dimensiones
- 80mm x 50mm (h x w)
- Grosor de la base
- 1.5mm
- Techniques:
- Ceiling recessed
- Interio/Exterior
- Indoor
- Acabado
-
Anodised: aluminium
Brushed anodised: champagne
Fine structured scratch resistant powder coating: black, white - Clasificación del IP
- IP20
- Prueba del hilo incandescente
- 960°C
- CRI
- 90+
- Garantía
- 5 years on LED lamps, 5 years on drivers
- Módulo de iluminación lineal
-
Medium power LED line
2700K, 3000K, 4000K
Non-dimmable, 1-10V, Dali/Pushdim - Módulo de iluminación spot
-
LED Array
Medium (25°)
2700K, 3000K
Trailing edge, 1-10V, Dali/Pushdim
Base Profile SLD50 Recessed
This base profile is merely 1.5mm thick and made of aluminium to ensure minimum weight, strength and durability. It comes with a maximum extruded length of 4 meters, thus offering the double benefit of preventing bending during transportation and making the profile easy to handle during installation.
Inner Cover SLD50 Naked
The aluminium cover of SLD50 Naked looks like a profile recessed within the base profile, thus giving its distinct design. Thanks to the fact that the lighting modules are directly mounted on it, it's easier to install and maintain by simply clicking-it on and off the base profile. Add an accent by choosing a different colour or go monochrome for a more understated look.
Modupoint system
Modupoint system
Modupoint LED
Especificaciones básicas
- Combina con Marbulito Jack, Marbulito Jack Suspended, Medard Jack, Minude Jack, Minude Jack Suspended
- 2700K, 3000K, 4000K (bajo pedido), Warm Dim
- Trailing Edge, 1-10V/Pushdim, Dali
Módulo de iluminación spot
Módulo de iluminación spot
Modupoint LED Stick
Eyeball 1x
Especificaciones básicas
- 2700K, 3000K, 4000K (no disponible para SLD50 Naked)
- Trailing edge, 1-10V, Dali/Pushdim
- 523lm (2700K) 544lm (3000K) 595lm (4000K)
Eyeball 2x
Especificaciones básicas
- 2700K, 3000K, 4000K (no disponible para SLD50 Naked)
- Trailing edge, 1-10V, Dali/Pushdim
- 622lm (2700K), 622lm (3000K)
Marbulito Jack Adjustable 41 1x
Especificaciones básicas
- 2700K, 3000K
- 1-10V, Pushdim, DALI y Trailing Edge
- 322lm (2700K), 702lm (3000K)
- Modupoint LED Stick necesario cuando se utiliza con SLD50 High y SLD50 Naked
Marbulito Jack Suspended 41 1x
Especificaciones básicas
- 2700K, 3000K
- 1-10V, Pushdim, DALI y Trailing Edge
- 322lm (2700K), 702lm (3000K)
Medard Jack Adjustable 42 1x
Especificaciones básicas
- 2700K, 3000K, 1800-3000K (Warm Dim)
- 1-10V, Pushdim, DALI y Trailing Edge
- 681lm (2700K), 695lm (3000K), 367lm (1800-3000K)
- Modupoint LED Stick necesario cuando se utiliza con SLD50 High y SLD50 Naked
Minude Jack Adjustable 45 1x
Especificaciones básicas
- 2700K, 3000K
- 1-10V, Pushdim, DALI y Trailing Edge
- 598lm (2700K), 610lm (3000K)
- Modupoint LED Stick necesario cuando se utiliza con SLD50 High y SLD50 Naked
Minude Jack Suspended 45 1x
Especificaciones básicas
- 2700K, 3000K
- 1-10V, Pushdim, DALI y Trailing Edge
- 598lm (2700K), 610lm (3000K)
Gamin Jack 90 1x
Especificaciones básicas
- 2700K, 3000K, 4000K and 1800-3000K (Warm Dim)
- 1-10V, Pushdim, DALI y Trailing Edge
- 676lm (2700K), 702lm (3000K), 365lm (1800-3000K)
- Modupoint LED Stick necesario cuando se utiliza con SLD50 High y SLD50 Naked
Módulo de iluminación lineal
Módulo de iluminación lineal
Linear LED Naked
Especificaciones básicas
- 2700K, 3000K, 4000K
- No regulable, 1-10 V, Dali/Pushdim
- 1067lm (2700K), 1090lm (3000K), 1896lm (2700K+), 2010lm (3000K+), 2110lm (4000K+)
