SLD50 High Recessed Trimless Su Misura

Il design elegante rende SLD50 High Recessed Trimless una soluzione perfetta per gli uffici che vogliono mettere in risalto le loro caratteristiche architettoniche. Dai carattere a un ambiente evidenziando elementi o motivi su pareti o soffitti. Questa applicazione senza finitura ti mostrerà solo splendide linee di luce.

Scheda tecnica Configure now

Technical support

Panoramica tecnica

Scheda tecnica

Avete bisogno di informazioni tecniche su questo sistema di profili? Fare clic per scaricare una scheda tecnica dedicata.

Scaricare

Dimensioni: 100mm x 50mm (h x w)
Spessore della base: 1.5mm
Techniques:: Ceiling recessed trimless
Interno/Esterno: Indoor
Finitura: Anodised: aluminium
Brushed anodised: bronze, champagne, silver bronze
Fine structured scratch resistant powder coating: black, white
Grado IP: IP20

Test filo a caldo: 960°C
CRI: 90+
Garanzia: 5 years on LED lamps, 5 years on drivers
Modulo di illuminazione lineare: High power LED line
2700K, 3000K, 4000K, 2700K-6500K tunable white
Non-dimmable, Dali/Pushdim: Flicker-free (AM dimming)
Available in preset dimmed version 50%
Modulo di illuminazione spot: LED Array
Medium (25°), Flood (40°)
2700K, 3000K, 4000K
Trailing edge, 1-10V, Dali/Pushdim

Base Profiles
Cover Profilo
Diffusori

Base Profile SLD50 High

This base profile is merely 1.5mm thick and made of aluminium to ensure minimum weight, strength and durability. It comes with a maximum extruded length of 4 meters, thus offering the double benefit of preventing bending during transportation and making the profile easy to handle during installation.

Cover SLD50

This aluminium cover matches the material of the base profile to ensure a consistent look. Click in-and-out, even after installation, to remove it without having to dismount the profile. The cover comes in a selection of colours to offer the choice of adding an accent or going monochrome for a more understated look.

Diffuser Poly In SLD50

The Poly In diffuser is flush mounted against the cover for a seamless design. Made of polycarbonate, this is a durable diffuser which keeps its quality over time. Click it-in and out for an easy installation and dismounting.

Diffuser Prismatic SLD50

Prismatic diffusers offer maximum reduction of glare and improve the UGR rating profiles. Made of polycarbonate, this is a durable diffuser which keeps its quality over time. Click it-in and out for an easy installation and dismounting.

Modupoint system

Modupoint LED

Specifiche di base

Combinalo con Marbulito Jack, Marbulito Jack Suspended, Medard Jack, Minude Jack, Minude Jack Suspended
2700K, 3000K, 4000K (su richiesta), Warm Dim
Trailing Edge, 1-10V/Pushdim, Dali
